Conquer the Unconquerable: Power Meets Precision
Welcome to Phantom 4WD N – Your Ultimate Off-Road Companion
Introducing the Phantom 4WD N, the pinnacle of four-wheel drive technology engineered for those who refuse to compromise on performance and capability. Designed for adventure seekers and everyday drivers alike, the Phantom 4WD N combines cutting-edge innovation with rugged durability to deliver an unmatched driving experience across all terrains.
| Engine | KIRLOSKAR 4R1040TA (BS III), 4-cylinder, turbocharged, water-cooled diesel engine delivering 96 HP @ 2200 rpm |
| Max Torque | 400 Nm @ 1400 rpm |
| Turning Radius (Without Brake) | 4.4 metres |
| Turning Radius (With Brake) | 3.5 metres |
| Transmission | Synchro shuttle transmission with torque converter & synchronised gearbox, 4 forward & 4 reverse speeds |
| Max Speed | 40 KMPH |
| Axle | Front: Drive (4WD) & Steer Axle, Rear: Rigid axle with CARRARO planetary drive |
| Steering | Hydrostatic steering for reliability and control |
| Tyres (Front) | 9.00-16-16 PR (2WD), 12.5/80-18-12 PR (4WD) |
| Tyres (Rear) | 16.90-28-12 PR (Standard) |
| Brakes | Hydraulically actuated wet disc brakes, twin pedals in cabin, mechanically actuated parking brakes |
| Overall Length | 6.2 M |
| Overall Height | 3.6 M |
| Height to Top of Cab | 2.9 M |
| Wheel Base | 2.18 M |
| Min Ground Clearance | 0.35 M |
| Slew Ground Clearance | 0.66 M |
| Width (Over Bucket) | 2.50 M |
| Track Width Front | 1.84 M |
| Track Width Rear | 1.55 M |
| Max Dig Depth | 4.60 M |
| Dump Height at 40° | 2.96 M |
| Loadover Height | 3.35 M |
| Bucket Pin Height | 3.63 M |
| Max Working Height | - |
| Reach at Ground | - |
| Reach at Full Height Bucket Dumped (40°) | - |
| Below Ground Level Dig Depth | - |
| Side Reach to Center Line | - |
| Bucket Rotation Power | - |
| King Post Travel | - |
